Fully Automatic Energy-saving Drying Machine Widely Used in Many Fields of Cans

Minimum Order Quantity :	1set	Price :	Negotiable
Packaging Details :	Wooden Case	Delivery Time :	90working days
Payment Terms :	T/T,L/C

Place of Origin:	China	Brand Name:	Sunnranpack
Certification:	CE

Detail Information
Dimension:	9009002200mm	Installed Power:	2kW
Air Consumption:	≥300L/min ＞0.5Mpa	Applicable Can Diameter:	φ52mm-φ350mm
Total Weight:	500 Kg	Powder Material:	Polyester Epoxies
Input Power:	AC 220V/50HZ	Coating Width:	6-14mm
Transfer Speed:	10-20m/min / 20-60m/min	Burner Power:	1-2KW
Burner Heating Speed:	4m-7m/min	Suitable Small Can Diameter:	Ф45mm-Ф176mm
Suitable Big Can Diameter:	Ф176mm-Ф350mm	Can Height:	45mm-600mm
Cooling Water:	>0.3MPa,23-28℃,40L/min	Air Consumption:	≥50L/min >0.3Mpa
Highlight:	fully automatic can drying machine , energy-saving tin can dryer , industrial can drying equipment

Product Description

Fully Automatic Energy-saving Drying Machine

Features:

With advanced design concept. This machine realized the production process of collection, kneading, rounding and welding.
Electrical control system adopts Mitsubishi or Omron programmable PLC controller, servo system and Mitsubishi motion control system to constitute intelligent digital control module.
The main electrical and pneumatic components are used internationally renowned brands, such as Schneider (France), Mitsubishi (Japan), Omron (Japan), Delta (Taiwan), SMC (Japan), AirTAC (Taiwan), etc to ensure our machine more stable.
Adopt Chinese and English HMI to do relevant adjustments, it is easy to do fault detection and eliminate fault quickly.
Change can type conveniently and quickly. Can pushing and feeding are used servo motors to make operation more convenient.
Unique mechanical structure, the main parts are used high quality materials of imported steel, super wear-resistant ceramics and hard alloy to make machine more durable.
The rounding machine has a unique design concept, has superior iron kneading function, and the reasonable design structure also plays a role in anti-scratching the can body. And it also guarantees that the product appearance is more perfect. Rounding machine lifting platform adopts scissors structure, which is more reliable and stable than traditional hydraulic lifting.
Unique intelligent speed control system, comes with precise clutch to controls the distance between cans effectively (to be adjustable between 1mm to 3mm), it can save copper wire and saving cost effectively.
The cooling system adopts advanced water flow control device, if the water flow cannot reach normal setting, the equipment will automatically alarm and stop working, it is good for cooling system protecting to ensure the service life of welding wheel.
Mercury-free welding system and remote control device are addable.

Parameters:

Burner heating speed	4m-7m/min
Burner power	1-2KW
Suitable small can diameter	Ф45mm-Ф176mm
Suitable big can diameter	Ф176mm-Ф350mm
Can height	45mm-600mm
Cooling water	>0.3MPa,23-28℃,40L/min
Air consumption	≥50L/min >0.3Mpa
