LED Curing Oven For Tinplate Printing Line

Product Description

LED curing oven for tinplate printing line

The LED curing oven is a cutting-edge technology used in the tinplate printing line to ensure efficient and high-quality curing of printed tinplate sheets. This advanced oven utilizes LED lights to provide a precise and uniform curing process, resulting in durable and vibrant prints.

One of the key advantages of the LED curing oven is its ability to emit a specific wavelength of light that matches the absorption spectrum of the ink. This targeted curing process ensures that the ink is fully cured, eliminating the risk of under-cured or over-cured areas on the tinplate sheets. As a result, manufacturers can achieve consistent and flawless prints with excellent color accuracy.

In addition to its precise curing capabilities, the LED curing oven operates at a lower temperature compared to traditional curing methods. This not only reduces energy consumption but also minimizes the risk of heat damage to the tinplate sheets. The lower temperature also allows for faster curing times, increasing the overall productivity of the printing line.

Power Consumption
Total Power: 36KW (2-color LED UV)

Lamp Lifetime

1.Designed Lifetime: 10,000h
2. Warranty: either 2 years or 10,000h, up to which comes first.
3. Instant ON/OFF, no need warming up, no standby power

Lamp-on Speed

Instant ON up to 100% when sheets detected at feeder, and
instant OFF when no sheets

Heating

Cold light source with very small heat, no infrared irradiance,
low temperature rise at sheet surface

Evenness

UVLED is made up 22 independent modules with separate
controlling, quite even light irradiance.

Environment Protection

No ozone produced

Spectrum

Wavelength 365nm-395nm just like usual illuminating ray.

Floor Space

LED UV Host 2.0m. no need cooling device (chiller is put at
side near electrical cabinet) Saved 3.5m of line length.
