Square can making machine square tin can production line 10-18L square can making machine

Price : $280,000.00 - $700,000.00/Pieces
Place of Origin: Guangdong, China Brand Name: Sunnran

Detail Information

Type: Packaging Line Applicable Industries: Food & Beverage Factory, Paint
Showroom Location: None Condition: New
Application: Food, Beverage, Chemical Packaging Type: Vacuum Packing , Wooden Case
Packaging Material: Tinplate Automatic Grade: Fully-automation
Driven Type: PLC Or Advanced Motion Control System Voltage: 380V
Dimension(L*W*H): 170000x2000x3050mm Weight: KG
Warranty: 1 Year Key Selling Points: High Quality With Competitive Price
Marketing Type: Ordinary Product Machinery Test Report: Provided
Video Outgoing-inspection: Provided Warranty Of Core Components: 1 Year
Core Components: PLC, Motion Control System Applicable Range:: Square Can
Output:: Max.45 CPM Applicable Can Height:: 150-380mm
Air Pressure:: Not Lower Than 0.6Mpa Connection Height:: 1000±10mm

Product Description

Products Description
Square can making line
Square can making machine square tin can production line 10-18L square can making machine 0
This line is designed for producing square can from 18L-20L. It adopts purely mechanical cam transmission, cam delivering can, cam holding can . Cans stuck protection system of this line is to make the production more secure. The internal & external grooved pulley design assures thee flanging more uniform and fast.
Applicable range
Max. speed
Thickness
Tinplate hardness
18-20L square can
42CPM
0.25-0.35mm
T2,T2.5,T3, some ofT4
Square can making machine square tin can production line 10-18L square can making machine 1
Square can making machine square tin can production line 10-18L square can making machine 2
Square can making machine square tin can production line 10-18L square can making machine 3
Square can making machine square tin can production line 10-18L square can making machine 4
Welding line
Square can making machine square tin can production line 10-18L square can making machine 5
Adopts sheet upward feeding to avoid double sheet issue. Can add additional storage platform for stocking the body blanks to enable machine continuously running and enhance productivity . With new innovated frequency inverter to make perfect welding seam. Internal and external roller coating machine is quipped with automatic lacquer feeding system to enable continuous operation. After roller coating , the lever-type mechanical brush can prevent the cylinder movement hit off the can bodies. Induction oven can be designed to linear or U-shape according to client’s workshop layout.
Automatic welder




Wire speed
Can diameter
Can height
Can material
Power capacity
9-24m/Min
200-260/260-290
180-450
Tinplate,Ni-plate,SS
26Kw
Internal & external coating machine




Coating speed
Can diameter
Coating width
Power Consumption
Power source
10-35m/min
52-300
10-14
0.6Kwh
220V
Induction oven




Conveying speed
Heater Qty.
Power
Cooling water
Air source
9-30m/min
3 x 2m/Heater
380V , 50Hz
>30L/min>400Kpa/cm2<20℃

Square can making machine square tin can production line 10-18L square can making machine 6
Square can making machine square tin can production line 10-18L square can making machine 7
